RS232 to USB Converter FTDI – LM060

£100.00

RS232 to USB Converter FTDI – LM060 is a smart and convenient accessory for connecting RS-232 serial devices to your USB-equipped host computer.

[av_button label=’Datasheet’ link=’manually,https://www.lm-technologies.comlm_downloads/LM060_DATASHEET.pdf’ link_target=’_blank’ size=’small’ position=’left’ icon_select=’yes-right-icon’ icon_hover=’aviaTBicon_hover’ icon=’ue832′ font=’entypo-fontello’ color=’dark’ custom_bg=’#444444′ custom_font=’#ffffff’]

[av_button label=’Where to Buy’ link=’page,471′ link_target=” size=’small’ position=’right’ icon_select=’yes-right-icon’ icon_hover=’aviaTBicon_hover’ icon=’ue832′ font=’entypo-fontello’ color=’dark’ custom_bg=’#444444′ custom_font=’#ffffff’]

Available: Out of stock

  • Tech Spec

    Additional Information

    Dimensions
    • 70mm x 36mm x 16mm
    Weight
    • 24.95g +/- 0.25g tolerance
    Data Rate

    Up to 6Mbps

    Compatibility
    • Linux
    • Mac OSX
    • Raspberry Pi
    • Windows 10
    • Windows 10 IoT Core
    • Windows 7
    • Windows 8
    • Windows Vista
    • Windows XP
    Compliance
    • CE
    • Reach
    • RoHS
    • WEEE
  • Description

    RS232 to USB Converter FTDI - LM060

    The LM060 provides a bridge connection with a standard DB9 male serial port connector in one end and a standard Type-A USB plug connector on the other end. The USB powers the converter to run the FTDI IC conversion.

    This USB to Serial adapter is ideal for connecting modems LM Bluetooth® Serial Adapters to a PC or can be used with devices such as digital cameras, card readers and other serial devices to your computer. It provides serial connections up to 1Mbps of data transfer rate. And since USB does not require any IRQ resource, more devices can be attached without the hassles of device resource conflicts.

    RS232 to USB Converter FTDI - LM060 Specifications

    • UART interface support for 7 or 8 data bits
    • 1 or 2 stop bits and odd / even / mark / space / no parity
    • Supported on Windows OS (32 bit and 64 bit) Linux and MAC OS
    • Integrated with a new FTDI Chipset - FT232RL
    • In-built support for event characters and line break condition
    • Fully assisted hardware or X-On / X-Off software handshaking
    • FIFO receive and transmit buffers for high data throughput
    • RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND
    • Operating temperature of -20°C to +80°C
  • Features

    • DB9 and USB connector
    • Up to up to 6M bits/sec data rate
    • Automatic handshaking is supported at the serial port
    • Plug and Play Installation
    • Robust construction
    • Common for our RS232 adapters
    • Low Cost solution

Case Studies

Lead Times Update 22 Sep 2022

For new orders, due to extended lead times from our chip vendors/suppliers, we are experiencing delays for key components used in LM products which are impacting the normal production cycle.…

Resources

Access all the information for our products - some documentation my require an account  to access.

Talk to us...

It’s what makes us stand out against our competitors, we are the experts, real people that can assist you – not just resellers.

Keep informed...

Alerts for EOL, PCN and products updates

Software

Please read before downloading

This product is plug and play, and it should be unnecessary to install any driver. However, we have supplied the following driver for your convenience if you encounter any problems.

[av_toggle_container initial=’0′ mode=’accordion’ sort=”]
[av_toggle title=’Read above before downloading’ tags=”]


[/av_toggle]

[/av_toggle_container]

Certifications

[av_toggle_container initial=’0′ mode=’accordion’ sort=”]

[av_toggle title=’EU Declaration of Conformity’ tags=”]

[/av_toggle]

[av_toggle title=’ISO9001 Declaration’ tags=”]

[/av_toggle]

[av_toggle title=’REACH, RoHS, WEEE Compliance’ tags=”]
[/av_toggle]

[/av_toggle_container]


Please use the Enquire tab to discuss certification.

RS232 to USB Converter FTDI – LM060

The LM060 provides a bridge connection with a standard DB9 male serial port connector in one end and a standard Type-A USB plug connector on the other end. The USB powers the converter to run the FTDI IC conversion.

This USB to Serial adapter is ideal for connecting modems LM Bluetooth® Serial Adapters to a PC or can be used with devices such as digital cameras, card readers and other serial devices to your computer. It provides serial connections up to 1Mbps of data transfer rate. And since USB does not require any IRQ resource, more devices can be attached without the hassles of device resource conflicts.

RS232 to USB Converter FTDI – LM060 Specifications

  • UART interface support for 7 or 8 data bits
  • 1 or 2 stop bits and odd / even / mark / space / no parity
  • Supported on Windows OS (32 bit and 64 bit) Linux and MAC OS
  • Integrated with a new FTDI Chipset – FT232RL
  • In-built support for event characters and line break condition
  • Fully assisted hardware or X-On / X-Off software handshaking
  • FIFO receive and transmit buffers for high data throughput
  • RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND
  • Operating temperature of -20°C to +80°C

Additional information

Dimensions
  • 70mm x 36mm x 16mm
Weight
  • 24.95g +/- 0.25g tolerance
Data Rate

Up to 6Mbps

Compatibility
  • Linux
  • Mac OSX
  • Raspberry Pi
  • Windows 10
  • Windows 10 IoT Core
  • Windows 7
  • Windows 8
  • Windows Vista
  • Windows XP
Compliance
  • CE
  • Reach
  • RoHS
  • WEEE

Documentation

[av_toggle_container initial=’0′ mode=’accordion’ sort=”]
[av_toggle title=’Harmonization Tariff Codes (HS Codes)’ tags=”]

[/av_toggle]
[/av_toggle_container]


* For other product Manuals, Notes and Guides please see our Download section
